| 1 | +# Usage |
| 2 | + |
| 3 | +To use it in Julia, first add it: |
| 4 | + |
| 5 | +``` |
| 6 | +(v1.1)> add TerminalUserInterfaces |
| 7 | +``` |
| 8 | + |
| 9 | +To build a Terminal User Interface (TUI), you'll need a main loop. |
| 10 | +`TerminalUserInterfaces.jl` is a library based on the immediate mode rendering concept. |
| 11 | +Every iteration of the main loop, the User Interface is "drawn" from scratch. |
| 12 | +This means writing out text to the screen every frame. |
| 13 | + |
| 14 | +While this may appear to be a limitation from a performance perspective, in practice it works well with stateful UI. |
| 15 | +Also to increase performance, `TerminalUserInterfaces.jl` maintains two buffers and draws only the difference between frames. |
| 16 | + |
| 17 | + |
| 18 | +``` |
| 19 | + START TUI.draw.(t, w) END |
| 20 | + *-------*-----*---*----*-----* |
| 21 | + ^ / |
| 22 | + \ v |
| 23 | + * <------* |
| 24 | + TUI.get_event(t) TUI.flush(t) |
| 25 | +``` |
| 26 | + |
| 27 | +## Example |
| 28 | + |
| 29 | +```julia |
| 30 | +using TerminalUserInterfaces |
| 31 | +const TUI = TerminalUserInterfaces |
| 32 | +``` |
| 33 | + |
| 34 | +### Initialize |
| 35 | + |
| 36 | +To create a TUI, the first thing you need to do is call `initialize` |
| 37 | + |
| 38 | + |
| 39 | +```julia |
| 40 | +TUI.initialize() |
| 41 | +``` |
| 42 | + |
| 43 | +This function does a few things: |
| 44 | + |
| 45 | +```julia |
| 46 | +tui_mode() |
| 47 | +hide_cursor() |
| 48 | +enable_raw_mode() |
| 49 | +clear_screen() |
| 50 | +move_cursor_home() |
| 51 | +``` |
| 52 | + |
| 53 | +- `tui_mode()`: starts an alternate buffer |
| 54 | +- `hide_cursor()`: makes cursor not visible |
| 55 | +- `enable_raw_mode()`: capture key presses as they happen without waiting for the enter key |
| 56 | +- `clear_screen()`: clear the screen of all text |
| 57 | +- `move_cursor_home()`: moves the cursor to the top left of the terminal window |
| 58 | + |
| 59 | +Every `TUI.initialize()` at beginning of a program must be paired with `TUI.cleanup()` at the end of a program. |
| 60 | + |
| 61 | +```julia |
| 62 | +move_cursor_home() |
| 63 | +clear_screen() |
| 64 | +disable_raw_mode() |
| 65 | +show_cursor() |
| 66 | +default_mode() |
| 67 | +``` |
| 68 | + |
| 69 | +After calling `initialize`, we can create the application. |
| 70 | +To start, let's create an instance of `Terminal`. |
| 71 | + |
| 72 | +```julia |
| 73 | +t = TUI.Terminal() |
| 74 | +``` |
| 75 | + |
| 76 | +This holds references to the frame buffers and allows us to call helper functions to create a TUI. |
| 77 | + |
| 78 | +### Draw Widgets |
| 79 | + |
| 80 | +Let's look at an example of a `SelectableList` widget. |
| 81 | + |
| 82 | + |
| 83 | + |
| 84 | +```julia |
| 85 | +w, _ = TUI.terminal_size() |
| 86 | +rect = TUI.Rect(1, 1, w ÷ 4, 20) |
| 87 | +widget = TUI.SelectableList( |
| 88 | + TUI.Block(title = "Option Picker"), |
| 89 | + words, |
| 90 | + scroll, |
| 91 | + selection, |
| 92 | +) |
| 93 | +TUI.draw(t, widget, rect) |
| 94 | +``` |
| 95 | + |
| 96 | +`TUI.draw(t, widget, rect)` calls `draw(list::SelectableList, area::Rect, buf::Buffer)` which implements how to draw the widget. |
| 97 | +The `Buffer` is a `Matrix{Cell}` where `Cell` contains a julia `Char` and information on how to style it. |
| 98 | + |
| 99 | +```julia |
| 100 | +struct Cell |
| 101 | + char::Char |
| 102 | + style::Crayons.Crayon |
| 103 | +end |
| 104 | +``` |
| 105 | + |
| 106 | +This is useful to know when implementing your own widgets. |
| 107 | + |
| 108 | +You can draw as many widgets as you want. If widgets are drawn at the same location, they will overwrite the `Cell` characters in the `Buffer`. |
| 109 | + |
| 110 | +Finally, calling `TUI.flush(t)` draws the current frame to the terminal. |
| 111 | + |
| 112 | +```julia |
| 113 | +TUI.flush(t) |
| 114 | +``` |
| 115 | + |
| 116 | +### Getting user input |
| 117 | + |
| 118 | +`TerminalUserInterfaces.jl` sets up `stdout` and `stdin` `Channel`s |
| 119 | + |
| 120 | +Calling `TUI.get_event(t)` reads from the `stdin` `Channel`. |
| 121 | + |
| 122 | +```julia |
| 123 | +function get_event(t) |
| 124 | + if isready(t.stdin_channel) |
| 125 | + return take!(t.stdin_channel) |
| 126 | + end |
| 127 | +end |
| 128 | +``` |
| 129 | + |
| 130 | +This function is non-blocking. You can also call `take!(t.stdin_channel)` to block till the user presses a key. |
| 131 | + |
| 132 | +Drawing, taking user input and acting on it and redrawing is what your main loop of the terminal user interface will look like. |
| 133 | + |
| 134 | +### Minimum Working Example |
| 135 | + |
| 136 | +```julia |
| 137 | +using TerminalUserInterfaces |
| 138 | +const TUI = TerminalUserInterfaces |
| 139 | +using Random |
| 140 | + |
| 141 | +function main() |
| 142 | + TUI.initialize() |
| 143 | + y, x = 1, 1 |
| 144 | + |
| 145 | + count = 1 |
| 146 | + t = TUI.Terminal() |
| 147 | + |
| 148 | + # TUI.enableRawMode() |
| 149 | + TUI.clear_screen() |
| 150 | + TUI.hide_cursor() |
| 151 | + |
| 152 | + words = [ |
| 153 | + "Option A" |
| 154 | + "Option B" |
| 155 | + "Option C" |
| 156 | + "Option D" |
| 157 | + "Option E" |
| 158 | + "Option F" |
| 159 | + "Option G" |
| 160 | + "Option H" |
| 161 | + "Option I" |
| 162 | + ] |
| 163 | + |
| 164 | + rng = MersenneTwister() |
| 165 | + styles = [ |
| 166 | + # TUI.Crayon(bold = true) |
| 167 | + # TUI.Crayon(italics = true) |
| 168 | + # TUI.Crayon(foreground = :red) |
| 169 | + # TUI.Crayon(foreground = :blue) |
| 170 | + # TUI.Crayon(foreground = :green) |
| 171 | + # TUI.Crayon(bold = true, foreground = :red) |
| 172 | + # TUI.Crayon(bold = true, foreground = :blue) |
| 173 | + # TUI.Crayon(bold = true, foreground = :green) |
| 174 | + # TUI.Crayon(italics = true, foreground = :red) |
| 175 | + # TUI.Crayon(italics = true, foreground = :blue) |
| 176 | + # TUI.Crayon(italics = true, foreground = :green) |
| 177 | + TUI.Crayon() |
| 178 | + ] |
| 179 | + |
| 180 | + words = [TUI.Word(word, styles[rand(rng, 1:length(styles))]) for word in words] |
| 181 | + |
| 182 | + scroll = 1 |
| 183 | + selection = 1 |
| 184 | + final = "" |
| 185 | + |
| 186 | + while true |
| 187 | + |
| 188 | + w, _ = TUI.terminal_size() |
| 189 | + |
| 190 | + r = TUI.Rect(x, y, w ÷ 4, 20) |
| 191 | + |
| 192 | + b = TUI.Block(title = "Option Picker") |
| 193 | + p = TUI.SelectableList( |
| 194 | + b, |
| 195 | + words, |
| 196 | + scroll, |
| 197 | + selection, |
| 198 | + ) |
| 199 | + |
| 200 | + TUI.draw(t, p, r) |
| 201 | + |
| 202 | + TUI.flush(t) |
| 203 | + |
| 204 | + count += 1 |
| 205 | + |
| 206 | + c = TUI.get_event(t) |
| 207 | + |
| 208 | + if c == 'j' |
| 209 | + selection += 1 |
| 210 | + elseif c == 'k' |
| 211 | + selection -= 1 |
| 212 | + elseif c == '\r' |
| 213 | + final = words[selection].text |
| 214 | + break |
| 215 | + end |
| 216 | + if selection < 1 |
| 217 | + selection = 1 |
| 218 | + end |
| 219 | + if selection > length(words) |
| 220 | + selection = length(words) |
| 221 | + end |
| 222 | + |
| 223 | + end |
| 224 | + |
| 225 | + TUI.cleanup() |
| 226 | + |
| 227 | + println(final) |
| 228 | + |
| 229 | +end |
| 230 | + |
| 231 | +main() |
| 232 | +``` |
